Tek Kademeli Vakum Pompaları
| MODEL | Giriş ve Çıkış Ağzı | Motor gücü (50 Hz'de) | Pompa Devri [devir/dak @ 50Hz] | Normal kapasite [m3/saat] | En yüksek kapasite [m3/saat] | Vakum basıncı-deniz seviyesi | Mutlak basınç | Servis suyu [lt/dak] | Su girişi | PDF Dosyası | |
| [kW] | 50Hz | 60Hz | mm Hg | mbar | |||||||
 | PVT 200/160 | DN 50 | 5,5 | 1450 | 170 | 290 | -680 | 100 | 30 | ½" |
|
|
| PVT 200/200 | DN 50 | 7,5 | 1450 | 270 | 400 | -680 | 100 | 35 | ½" |
|
 | PVT 230/240 | DN 50 | 11 | 1450 | 430 | 560 | -700 | 80 | 45 | ¾" |
|
|
| PVT 230/300 | DN 65 | 15 | 1450 | 470 | 600 | -700 | 80 | 50 | ¾" |
|
 | PVT 275/220 | DN 80 | 15 | 1450 | 500 | 650 | -730 | 40 | 50 | 1" |
|
|
| PVT 275/260 | DN 80 | 18,5 | 1450 | 600 | 800 | -730 | 40 | 55 | 1" |
|
|
| PVT 275/300 | DN 80 | 22 | 1450 | 700 | 850 | -730 | 40 | 60 | 1" |
|
|
| PVT 275/400 | DN 100 | 30 | 1450 | 1200 | 1450 | -710 | 60 | 110 | 1" |
|
|
| PVT 275/500 | DN 100 | 37 | 1450 | 1300 | 1600 | -710 | 60 | 120 | 1" |
|
| PVT 420/350 | DN 125 | 37 | 980 | 1500 | 2000 | -730 | 40 | 90 | 1½" |
| |
| PVT 420/400 | DN 125 | 45 | 980 | 1800 | 2250 | -730 | 40 | 100 | 1½" |
| |
 | PVT 520/350 | DN 200 | 55 | 735 | 2100 | 2650 | -600 . -680 | 200 - 100 | 200 | 2" |
|
|
| PVT 520 450 | DN 200 | 75 | 735 | 2700 | 3400 | -600 . -680 | 200 - 100 | 220 | 2" |
|
|
| PVT 520/700 | DN 200 | 90 | 735 | 3800 | 4400 | -600 . -680 | 200 - 100 | 250 | 2" |
|
|
| PVT 520/800 | DN 200 | 110 | 880 | 4550 | 4800 | -600 . -680 | 200 - 100 | 280 | 2" |
|
|
| PVT 520/850 | DN 200 | 132 | 950 | 4900 | 5400 | -600 . -680 | 200 - 100 | 290 | 2" |
|
 | PVT 650/500 | DN 300 | 132 | 490 | 5200 | 5750 | -600 . -680 | 200 - 100 | 300 | 3" |
|
|
| PVT 650/600 | DN 300 | 160 | 590 | 6000 | 6600 | -600 . -680 | 200 - 100 | 330 | 3" |
|
|
| PVT 650/700 | DN 300 | 160 | 670 | 7000 | 7500 | -600 . -680 | 200 - 100 | 350 | 3" |
|
|
| PVT 700/400 | DN 300 | 200 | 390 | 8000 | 9600 | -600 . -680 | 200 - 100 | 400 | 3" |
|
|
| PVT 700/500 | DN 300 | 250 | 490 | 10000 | 12000 | -600 . -680 | 200 - 100 | 450 | 3" |
|
|
| PVT 700/600 | DN 300 | 315 | 590 | 11700 | 14050 | -600 . -680 | 200 - 100 | 500 | 3" |
|
|
| PVT 700/700 | DN 300 | 355 | 670 | 12500 | 15000 | -600 . -680 | 200 - 100 | 550 | 3" |
|
|
| PVT 800/400 | DN 350 | 315 | 400 | 13500 | 16200 | -600 | 200 | 700 | 4" |
|
|
| PVT 800/500 | DN 350 | 355 | 485 | 16500 | 19800 | -600 | 200 | 750 | 4" |
|
|
| PVT 800/600 | DN 350 | 400 | 590 | 20000 | 24000 | -600 | 200 | 900 | 4" |
|
